Specifications:
HIGHLIGHTS
- 8,500 Hours Total Time
- Engines Enrolled on ESP Gold
- 12-Year Inspection c/w August 2014 at Bombardier FLL
- ATG-5000 WiFi
- 3-Rotor Brake Upgrade
- Currently on Part 135 Certificate
- ADS-B Out Deposit made with slot booked for installation
AIRFRAME (as of April 11th 2018)
8,514 Hours / 5,913 Cycles
ENGINES
Pratt & Whitney PW306A on ESP GOLD
LEFT RIGHT
TTSN (Hours) 8,114 8,344
TCSN 5,613 5,775
INTERIOR
New interior in August 2014 by Bombardier, Fort Lauderdale
Fireblocked 8-Passenger configuration including four executive club seats in the rear, two-seat divan facing a single executive seat in the front, in addition to the belted lavatory. Forward galley. External baggage compartment. Headliner and sidewalls are Monaco and Volaero Munich leather from Aeristo. Carpet is Costa Rica tweed from AIP, and woodwork is high gloss striped sapeje.
EXTERIOR
New Paint in 2012 by Bombardier FLL (ONLY flown 400 hours since)
New stripes in May 2017.
AVIONICS
- Collins Pro Line 4 EFIS / Avionics System includes:
- Dual Collins ADC-850D Air Data Computers
- Dual Collins AHC-85E Altitude Headline Computers
- Dual Universal UNIS-1C FMS w/dual GPS
- Dual Collins FCC-850A Flight Control Computers
- Dual Collins VIR-432 Nav Units
- Dual Collins VHF-422A Comm Units
- Dual Honeywell 800 Digital Acquisition Units
- Four tube Collins EFD/MFD-871 with 7” x 8” Displays
- Dual TDR-94D Mode S” Transponders
- Collins TTR920 TCAS w/change 7.1
- Collins WXR-840/RTA-844 Color Weather Radar System
- Collins ALT-55B Radio Altimeter
ADDITIONAL FEATURES
- ATG-5000 Internet w/ Wifi
- Honeywell Mark V EGPWS with Windshear Alert
- Universal CVR-30B Cockpit Voice Recorder
- Artex C460-2 MHz ELT w/Nav Interface
- Pulse lights
- Dual Concorde lead acid batteries
- Aircell Access EZ Airborne Phone System
- 3-Way Rotorway Brakes Upgrade
- RVSM Compliant
- Baggage Compartment Smoke Detector
- 115 VAC outlets
- SONY 10 disc C.D. charger
- Mapco warming oven
- Audio International VCP player & 10.4” Fwd Monitor
- Airshow 400 disc C.D charger
MAINTENANCE
- 12-Month Inspection c/w March 2018 – Next due March 2019
- 24-Month Inspection c/w March 2017 – Next due March 2019
- 48-Month Inspection c/w March 2017 – Next due March 2021
- 96-Month Inspection c/w March 2013 – Next due March 2021
- 144-Month Inspection c/w September 2014 – Next due September 2026
- 6000-Cycles Gear Inspection c/w November 2018
- New windshield installed in March 2017
- On Part 135 Certificate
- Excellent history and records
WEIGHTS
Gross Weight (Ramp): 23,750 lbs
Max Take off Weight: 23,500 lbs
Max Landing Weight: 19,600 lbs
Max Zero Fuel Weight 17,000 lbs
Empty Weight: 14,460 lbs
